Description

LOA 40.54 m
Beam 30.5 m
Draft 4 m

Built in year 2005, rebuilt in 2008
Class : DNV
Flag : Taiwan
Gross Tonnage of 1,142 and Nett Tonnage of 342

3 legs of 79m length for max water depth of 63m
1 Crane / Gear installed with a max lifting capacity of 100 tons
1 Crane / Gear installed with a max lifting capacity of 15 tons
Free Deck area about 759m²

Total passenger capacity 150

Engines : 2 x Caterpillar / Caterpillar Inc 3508B, 1,412 kw, 1,600 rpm, Propellers 1 x Port Side + 1 x Starboard
Auxiliaries Engines : 2 Caterpillar 175 kw, Bowthruster (1 Bow Tunnel thruster 492hp)

Specifications

Engine(s)

2 x 1,412 kw, 1,600 rpm, Caterpillar / Caterpillar Inc 3508B,
Propellers: 1 x Port Side + 1 x Starboard

Certification

REGISTERED Achilles Member:
- UVDB Registered
- CONNEXIO Accredited
- SELLIHCA Qualified

MEMBER Renewable Energy Hamburg
MEMBER Bundesverband Windenergie
MEMBER Windenergie Agentur Bremerhaven
MEMBER Windenergy Network

Disclaimer

GRS performs its services exclusively on the basis of its General Terms and Conditions, which are available at the GRS website www.grs-offshore.com.
All details are given in good faith but without guarantee. Subject to availability.
